1734035-1
Manufacturer:
TE Connectivity
Mfr.Part #:
1734035-1
Datasheet:
Description:
Audio / Video Connectors SMD/SMT Female Number of Positions:5 Right Angle USB - mini B
| Parameter | Value |
|---|---|
| Max Operating Temperature | 50 °C |
| Min Operating Temperature | 0 °C |
| Packaging | Tray |
| RoHS | Compliant |
| Insulation Resistance | 100 MΩ |
| Contact Plating | Gold Flash, Gold Flash over Nickel |
| Contact Material(Contact Finish) | Phosphor Bronze |
| Flammability Rating | UL94 V-0 |
| Orientation | Right Angle |
| Lifecycle Status | Active |
| Gender | Female |
| Number of Contacts | 5 |
| Mounting Style | Horizontal, Surface Mount, PCB |
| lead free status | Lead Free |
| operating temperature | -40.0 °C to 85.0 °C |
| rohs status | Compliant |
| reach svhc compliance | No SVHC |
| Connector Type | USB - mini B |
| Number of Positions | 5 |
| Housing Material | Nylon |
| Contact Resistance | 50 mΩ |
| size width | 7.70 mm |
| size length | 8.45 mm |
| size height | 3.90 mm |
| elv compliant | Compliant |
| Housing Color | Black |
Stock: 2518
Distributors
pcbx
pcbxUnit Price$0.96518
Ext.Price$0.96518
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.96518 | $0.96518 |
| 10 | $0.80458 | $8.04580 |
| 25 | $0.73845 | $18.46125 |
| 50 | $0.67776 | $33.88800 |
| 100 | $0.62205 | $62.20500 |
| 300 | $0.57092 | $171.27600 |
| 500 | $0.52400 | $262.00000 |
| 1000 | $0.48093 | $480.93000 |
